Description
ADVANTAGES
- Easily grind end mill and drill
- One machine has double functions(mill and drill), with easy operation and lower cost.
- With CBN or SDC(alternative), longer service life.
- The milling cutter can grind 2-flutes, 3-flutes, 4-flutes, 6-flutes and so on.
- Drill bit can be sharpened the major cutting lip angle, lip relief angle and front angle and point angle of drill and mill bit, you also can control the centre spot at random instend of centre drill, easy vent scraps, relaxed drilling and milling.
SPECIFICATION
| Model: | End Mill | Drill |
| Range: | Φ4-Φ14MM | Φ3-Φ14MM |
| Point Angle: | 0°~5° | 100°~135° |
| Voltage: | AC220V | |
| Power: | 180W | |
| Motor: | 4800RPM | |
| Dimension: | 37*23*30CM | |
| Weight: | 20KG | |
| Standard Model: | Grinding Wheel for Drill: CBN (for HSS)*1 | |
| Grinding Wheel for Mill: CBN(for HSS)*1 | ||
| One collet chuck for drill;
Two collet chucks for end mill: 2,4 flutes*1 piece 3,6 flutes*1 piece |
||
| Optional Model: | Grinding Wheel for Drill: SDC (for Carbide) | |
| Grinding Wheel for Mill: SDC (for Carbide) | ||
